Use the Caterpillar Monitoring System or use the Caterpillar Electronic Technician in order to determine the diagnostic codes for the power train ECM. After determining the diagnostic codes, refer to the corresponding test procedure for more information. Perform the procedure that corresponds to the diagnostic code (CID and FMI). The following table is a list of possible diagnostic codes for the ECM.
Table 1
Diagnostic Codes For The Power Train ECM (MID 081) (1)
For troubleshooting, see the procedure with the same diagnostic code.
CID/FMI Description
CID 0168 Electrical System Voltage
FMI 01 'Below normal range'
CID 0177 Temperature Sensor (Transmission Oil)
FMI 03 'Voltage above normal or shorted high'
FMI 04 'Voltage below normal'
CID 0248 Cat Data Link
FMI 02 'Incorrect signal'
CID 0268 Programmable Parameter
FMI 02 'Incorrect signal'
CID 0444 Magnetic Switch (Start Relay)
FMI 03 'Voltage above normal or shorted high'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
CID 0520 Configuration (Transmission)
FMI 02 'Incorrect signal'
CID 0562 Caterpillar Monitoring System
FMI 09 'Abnormal update'
CID 0573 Position Sensor (Clutch Pedal)
FMI 03 'Voltage above normal or shorted high'
FMI 04 'Voltage below normal'
FMI 13 'Out of calibration'
CID 0585 Speed Sensor (Transmission Output) (No. 1)
FMI 02 'Incorrect signal'
CID 0637 Backup Alarm
FMI 06 'Current above normal'
CID 0668 Transmission Control (Shift Lever)
FMI 02 'Incorrect signal'
FMI 03 'Voltage above normal'
CID 0669 Speed Sensor (Transmission Input)
FMI 02 'Incorrect signal'
CID 0673 Speed Sensor (Transmission Output) (No. 2)
FMI 02 'Incorrect signal'
CID 0688 Solenoid Valve (Dual Horsepower)
FMI 06 'Current above normal'
CID 0868 Indicator Lamp (Automatic shift)
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
CID 1401 Solenoid Valve (Forward High)
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
FMI 13 'Out of Calibration'
CID 1402 Solenoid Valve (Forward Low)
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
FMI 13 'Out of Calibration'
CID 1403 Solenoid Valve (Reverse)
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
FMI 13 'Out of Calibration'
CID 1404 Solenoid Valve (Speed Clutch) (No. 2)
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
CID 1405 Solenoid Valve (Speed Clutch) (No. 3)
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
CID 1406 Solenoid Valve (Speed Clutch) (No. 1)
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
CID 1407 Solenoid Valve (Low Range)
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
CID 1408 Solenoid Valve (High Range)
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'
CID 1484 Limit Switch (Clutch Pedal)
FMI 03 'Voltage above normal'
FMI 04 'Voltage below normal'
CID 1580 Indicator Lamp (Transmission Filter Bypass )
FMI 03 'Voltage above normal'
FMI 05 'Current below normal'
FMI 06 'Current above normal'

Cat 12 Motor Grader Manual

Show/hide table
( 1 ) For the Power Train ECM, the MID is 081. This table pertains only to diagnostic codes with a MID of 081.

Note: This table shows the diagnostic codes for the power train ECM only. The diagnostic codes for the ECM are shown on the display area of the Caterpillar Monitoring System. The information of the diagnostic code for the ECM is transferred via the Cat data link to the Caterpillar Monitoring System. This diagnostic information is shown when the Caterpillar Monitoring System is in the service mode. The module identifier (MID) tells the service person the ECM that is sending the diagnostic code. The MID for the power train ECM is 081. This Service Manual is used for diagnostic codes with the MID 081. The Electrical System Schematic shows the module identifier (MID) codes of any other electronic controls on a machine. Information for electronic troubleshooting of the diagnostic codes (MID is not 081) can be found in the service manual for that system.

Usage:

12H ES2GS

Illustration 1g00689096

The Electronic Monitoring System (EMS) is located on the front dash in the operator compartment. The EMS consists of an action alarm, action light (1), and monitoring panel (2). The monitoring panel includes an individual alert indicator for each machine system that is listed on the monitoring panel.

The EMS is designed to alert the operator to an immediate problem with any of the machine systems that are monitored. The EMS is also designed to alert the operator to an impending problem with any of the machine systems that are monitored. The action light and the individual alert indicators will light when a problem occurs.

EMS Functional Test

To ensure the proper operation of the EMS, check the system daily.

The battery disconnect switch must be in the ON position in order to supply electrical power to the machine.

Show/hide table

Illustration 2g00717994

When you turn engine start switch (3) to the ON position, electrical power is supplied to the systems in the operator compartment.


Illustration 3g00689029
Show/hide table

Panel Test Switch (4) - While the engine is not running, push up on the panel test switch in order to test the EMS. All alert indicators should come on and the action light should blink until panel test switch (1) is released. The panel test switch will return to the OFF position when the panel test switch is released.

If the alert indicators or action light (1) do not come on, the electrical system must be checked. Perform all necessary repairs before you start the engine.

If all of the alert indicators and action light (1) come on, start the engine. Repeat the panel test with the engine running. Move panel test switch (4) to the ON position. All alert indicators and action light (1) should come on again. The action alarm should also sound.

If any of the alert indicators or the action light do not come on or action alarm (1) does not sound, stop the engine. Check the electrical system and the machine system. Perform all necessary repairs before you start the engine.

Warning Categories

The Electronic Monitoring System (EMS) provides three warning categories. The first warning category requires only operator awareness. The second warning category requires an operator response. The third warning category requires immediate shutdown of the machine systems.

Warning Category 1

In this category, only the alert indicator comes on. This category alerts the operator that the machine system needs attention. Failure of these systems will not endanger the operator. Failure of these systems will not cause serious damage to the machine components.

Caterpillar 12H, 140H & 160H Motor Graders Factory Service ...


Illustration 4g00689016
Show/hide table

Parking Brake (5) - This alert indicator shows that the parking brake is engaged and that the transmission is in the NEUTRAL position. The alert indicator should come on during engine start-up. The alert indicator should go out when the parking brake is disengaged.

Alternator (6) - This alert indicator shows that the alternator is malfunctioning. If this alert indicator comes on, stop the machine at a convenient location. Investigate the cause of the problem. The cause of the problem could be a loose belt, a broken belt, etc. Do not operate the machine until the cause of the problem has been corrected.

Warning Category 2

In this category, the alert indicator and the action light come on. This category requires a change in machine operation in order to reduce excessive temperature in one of the machine systems or more.

Show/hide table

Illustration 5g00689018

Coolant Temperature (7) - This alert indicator shows excessive coolant temperature. If this alert indicator comes on, reduce the operating speed of the machine. Keep the engine at low idle until the engine is cooled down. If the alert indicator should stay on for several minutes after running the engine at low idle, stop the engine. Investigate the cause of the problem.

Do not operate the machine if the alert indicator stays on and the action light flashes. Make any necessary repairs.

Show/hide table

Transmission Electrical System (8) - This alert indicator shows an electrical fault in the transmission electrical system. Stop the machine at a convenient location if the indicator stays on. Investigate the cause of the problem. Do not operate the machine if the alert indicator stays on and the action light flashes.

Hydraulic Oil Temperature (9) - This alert indicator shows excessive hydraulic oil temperature. If this alert indicator comes on, reduce the load on the hydraulic system. Stop the machine at a convenient location if the alert indicator stays on. Investigate the cause of the problem. Do not operate the machine if the alert indicator stays on and the action light flashes.

Warning Category 3

In this category, the alert indicator and the action light come on and the action alarm sounds. This category requires immediate shutdown of the machine in order to prevent injury to the operator and/or severe damage to the machine.

Show/hide table

12h
Illustration 6g00689019

Primary Steering (10) - This alert indicator shows that the primary steering has failed and that the secondary steering is being used. If this alert indicator comes on during operation, steer the machine to a safe location and stop the machine. Stop the engine and investigate the cause of the problem. Do not operate the machine until the cause of the problem has been corrected.
Show/hide table

Engine Oil Pressure (11) - This alert indicator shows low engine oil pressure. If this alert indicator comes on, stop the machine immediately. Stop the engine and investigate the cause of the problem. Do not operate the machine until the cause of the problem has been corrected.

Brake Air Pressure (12) - This alert indicator shows low brake air pressure. If this alert indicator comes on, stop the machine immediately. Stop the engine and investigate the cause of the problem. Do not operate the machine until the cause of the problem has been corrected.
Show/hide table

Illustration 7g00689020

Parking Brake (13) - This alert indicator notifies the operator that the parking brake is engaged. Stop the machine immediately if all of the following conditions occur:
  • The alert indicator turns on.
  • The action light turns on.
  • The action alarm sounds.

Engage the parking brake and stop the engine. Investigate the cause of the problem.

Do not operate the machine until the cause of the problem has been corrected.

Cat 12h Grader Operators Manual

If the parking brake is engaged and the transmission is engaged during engine start-up, the following conditions will occur:

  • The alert indicator will come on.
  • The action light will flash.
  • The action alarm will sound.

Cat 12h Grader Parts Manual Pdf

Shift the transmission direction and speed control to the NEUTRAL position in order to turn off the action alarm.
